Data Sources

Applies to:

DashboardCLIServiceNowCloud KMSHSMGit Providers

Dashboard means DuoKey Cockpit

The "dashboard" and data-source sync described on this page are configured inside DuoKey Cockpit (the PQC Readiness module) — there is no separate local web server or localhost dashboard shipped by dke-scanner-agent. Some of the CLI examples below (e.g. servicenow, cloud-aws, vanta, drata, integrations status) illustrate the sync concept but are not real dke-scanner-agent subcommands; the actual CLI surface is documented in the CLI Reference. Real scans are run with commands such as filesystem, domain, inventory, source-code, cloud, or vault, and the resulting JSON is uploaded to the Cockpit for compliance checks and integration sync.

Quick Reference

Category	Data Source	Description	Status
ITSM / CMDB	ServiceNow	CMDB integration with incident management	Production
HSM / KMS	Securosys CloudHSM	Hardware Security Module key inventory	Production
HSM / KMS	DuoKey KMS	Multi-tenant key management service	Production
Firewall / Network	Fortinet FortiGate	Firewall certificates, VPN, SSL inspection	Production
Firewall / Network	Palo Alto Networks	Next-gen firewall certificates and VPN configs	Planned
Firewall / Network	Check Point	Check Point firewall and VPN gateway discovery	Planned
Firewall / Network	F5 BIG-IP	Application delivery controller, SSL certificates, TLS	Planned
Firewall / Network	Cisco ASA/Firepower	Cisco firewall certificates and VPN configuration	Planned
Firewall / Network	Barracuda	Barracuda firewall and WAF certificate discovery	Planned
Firewall / Network	Citrix ADC	Citrix NetScaler/ADC SSL certificate management	Planned
Firewall / Network	FortiManager	Centralized Fortinet management and certificate sync	Planned
Cloud KMS	AWS KMS	Amazon Web Services Key Management Service	Production
Cloud KMS	Azure Key Vault	Microsoft Azure Key Vault	Beta
Cloud KMS	Google Cloud KMS	Google Cloud Platform Key Management	Beta
Source Code / Git	GitHub	GitHub repositories and GitHub Enterprise	Production
Source Code / Git	GitLab	GitLab repositories and self-hosted instances	Production
Source Code / Git	Azure DevOps	Azure DevOps repositories and pipelines	Production
SSH / Keys	SSH Keys	SSH agent, user keys, authorized_keys, server host keys	Production
SSH / Keys	Cockpit SSH	Cockpit-managed SSH keys and certificates	Production
Network / TLS	TLS/SSL Endpoints	Remote HTTPS endpoints, certificate chains, cipher suites	Production
Advanced	Network Scanner	Network-wide cryptographic asset discovery	Planned
Advanced	Packet Capture	Post-quantum key exchange detection via packet analysis	Alpha
Advanced	Domain/Subdomain	Automated discovery across domains and subdomains	Alpha

Overview

Data Source Capabilities

Import

Import cryptographic assets from external systems

Synchronize

Synchronize asset inventories automatically

Track

Track assets across multiple platforms

Integrate

Integrate with existing security tools

Supported Data Sources

1. ServiceNow

Integrate with ServiceNow CMDB to track cryptographic assets alongside other IT assets.

Features

Bi-directional syncSync with ServiceNow tables

Auto-incident creationFor critical findings

Custom table supportUse your own ServiceNow tables

Real-time updatesVia webhooks

Configuration

Via Dashboard:

Navigate to Settings

Navigate to Settings → Data Sources

Select ServiceNow

Click Configure on ServiceNow card

Enter Details

Field	Description	Required
Instance URL	Your ServiceNow instance (e.g., https://company.service-now.com)	Yes
Username	ServiceNow username for basic auth	Yes*
Password	ServiceNow password for basic auth	Yes*
OAuth Token	OAuth token (alternative to username/password)	Yes*
API Table	Custom table name	No (default: x_1598283_post_q_0_x_pqc_crypto_asset)
Auto-Create Incidents	Automatically create incidents for critical findings	No (default: true)

* Either username/password or OAuth token required

Via CLI:

# Set environment variables
export SERVICENOW_INSTANCE="https://company.service-now.com"
export SERVICENOW_USER="admin"
export SERVICENOW_PASSWORD="your-password"
# Or use OAuth token
export SERVICENOW_TOKEN="your-oauth-token"

# Test connection
dke-scanner-agent servicenow --test-connection

# Publish scan results
dke-scanner-agent servicenow --input scan-results.json

Testing Connection

Via Dashboard:

Click Test Connection button
Wait for result: Success or Failure
Review error messages if connection fails

Via CLI:

dke-scanner-agent servicenow \
  --instance https://company.service-now.com \
  --token $SERVICENOW_TOKEN \
  --test-connection

2. Securosys CloudHSM

Import cryptographic keys from Securosys CloudHSM for quantum readiness assessment.

Features

Direct HSM key inventoryRead keys from HSM partitions

Key usage analyticsTrack key usage patterns

Algorithm complianceCheck algorithm compliance

Key rotation planningAutomated rotation plans

Configuration

Via Dashboard:

Navigate to Settings

Navigate to Settings → Data Sources

Select Securosys CloudHSM

Click Configure on Securosys CloudHSM card

Enter Details

Field	Description	Required
API URL	Securosys CloudHSM API endpoint	Yes
API Token	Authentication token	Yes
Environment	production, staging, or development	No

API Token Generation:

Log in to Securosys CloudHSM console
Navigate to Settings → API Tokens
Click Generate New Token
Select scopes: key:read, key:list
Copy and save the token securely

3. Fortinet FortiGate

Discover cryptographic assets in Fortinet FortiGate firewalls including certificates, VPN configurations, and SSL/TLS settings.

Features

SSL/TLS certificate discoveryLocal and CA certificates

VPN IPSec configurationsPhase 1 & 2 interfaces, DH groups

SSL VPN certificatesServer certs, TLS versions, cipher suites

Deep inspection certificatesSSL inspection certificates and keys

Configuration

Via Dashboard:

Navigate to Settings

Navigate to Settings → Data Sources

Select Fortinet FortiGate

Click Configure on Fortinet FortiGate card

Enter Details

Field	Description	Required
Base URL	FortiGate base URL (e.g., https://192.168.1.1)	Yes
API Token	FortiGate API access token (Bearer token)	Yes
Skip SSL Verify	Skip SSL certificate verification for self-signed certs	No (default: true)
Timeout	Connection timeout in seconds	No (default: 30)

API Token Generation

Log in to FortiGate web interface
Navigate to System → Administrators
Create a new REST API Admin
Generate API token with required permissions: certificate (read), vpn.ipsec (read), vpn.ssl (read)
Copy and save the token securely

Risk Analysis

The scanner automatically detects:

Quantum-vulnerable algorithms: RSA-2048, ECDSA, weak DH groups
Weak TLS versions: TLS 1.0, TLS 1.1
Certificate expiration: Upcoming expiry dates
Private key exposure: Keys accessible via API
Weak VPN configurations: DH groups 1, 2, 5

4. AWS KMS

Discover and assess cryptographic keys in AWS Key Management Service across multiple regions.

Features

Multi-region key discoveryScan across AWS regions

Customer managed keysCMK analysis

External key storesXKS and CloudHSM keys

Key rotation statusAlgorithm & key spec analysis

Configuration

Via Dashboard:

Navigate to Settings

Navigate to Settings → Data Sources

Select AWS KMS

Click Configure on AWS KMS card

Enter Details

Field	Description	Required
AWS Access Key ID	IAM access key with KMS permissions	Yes
AWS Secret Access Key	IAM secret access key	Yes
Regions	AWS regions to scan (comma-separated)	Yes

Supported Key Types

The scanner analyzes all AWS KMS key specs:

Symmetric: AES-256, AES-128
Asymmetric RSA: RSA-2048, RSA-3072, RSA-4096
Asymmetric ECC: ECC_NIST_P256, ECC_NIST_P384, ECC_NIST_P521, ECC_SECG_P256K1
SM2: Chinese cryptographic standard

Quantum Risk Assessment

Key Spec	Algorithm	Quantum Vulnerable	Risk Score
SYMMETRIC_DEFAULT	AES-256	No	Low
RSA_2048	RSA-2048	Yes	High
RSA_3072	RSA-3072	Yes	Medium
RSA_4096	RSA-4096	Yes	Medium
ECC_NIST_P256	ECDSA P-256	Yes	High

5. Azure Key Vault

Integrate with Microsoft Azure Key Vault for comprehensive key and certificate inventory.

Features

Key discoveryAcross subscriptions

Certificate managementFull cert inventory

Managed HSMHSM-backed keys

Access policy reviewKey versioning tracking

Configuration

Via Dashboard:

Field	Description	Required
Tenant ID	Azure AD tenant identifier	Yes
Client ID	Application (client) ID	Yes
Client Secret	Application client secret	Yes
Subscription ID	Azure subscription ID	Yes

Service Principal Setup

Register an application in Azure AD
Create a client secret
Assign Key Vault permissions:
- Key Vault Reader role on subscription
- Key Vault Crypto User for key operations
- Key Vault Certificates User for certificates

Supported Operations

List all key vaults in subscription
Enumerate keys and certificates
Analyze key types (RSA, EC, AES)
Check key sizes and curves
Review expiration dates
Assess quantum vulnerability

6. Google Cloud KMS

Discover cryptographic keys across Google Cloud Platform projects.

Features

Multi-project discoveryScan across GCP projects

Key ring enumerationFull key ring inventory

HSM & software keysBoth key types detected

IAM policy reviewAlgorithm analysis & versioning

Configuration

Via Dashboard:

Field	Description	Required
Service Account JSON	GCP service account credentials	Yes
Projects	GCP project IDs (comma-separated)	Yes

Service Account Setup

Create a service account in GCP Console
Grant roles:
- Cloud KMS Viewer
- Cloud KMS CryptoKey Decrypter (if analyzing key usage)
Create and download JSON key
Paste JSON content into scanner configuration

Supported Key Types

GOOGLE_SYMMETRIC_ENCRYPTION
RSA_SIGN_PSS_2048_SHA256
RSA_SIGN_PSS_3072_SHA256
RSA_SIGN_PSS_4096_SHA256
EC_SIGN_P256_SHA256
EC_SIGN_P384_SHA384

7. DuoKey KMS

Integrate with DuoKey Key Management Service for comprehensive key lifecycle management.

Features

Centralized key inventoryFull key lifecycle management

Multi-tenant supportIsolate per tenant

OAuth 2.0 authenticationSecure token-based access

Real-time monitoringAutomated compliance reporting

Configuration

Via Dashboard:

Field	Description	Required
API URL	DuoKey KMS API endpoint (e.g., https://kms.duokey.com)	Yes
Tenant ID	Your organization's tenant identifier	Yes
Client ID	OAuth client ID	Yes
Client Secret	OAuth client secret	Yes
Username	KMS username	Yes
Password	KMS password	Yes
Scope	OAuth scope	No (default: default-api)

Authentication Flow

The scanner uses OAuth 2.0 Resource Owner Password Credentials flow:

OAuth 2.0 password flow

PQC Scanner

1. POST /connect/token — grant_type=password, client_id, client_secret, username, password, scope

DuoKey KMS

2. Access token — token_type Bearer, expires_in 3600

PQC Scanner — authenticated

3. GET /api/keys — Authorization Bearer token

DuoKey KMS

4. Key inventory — cryptographic assets with risk scores

PQC Scanner — key inventory

The scanner exchanges KMS password credentials for a bearer token, then pulls the key inventory with risk scores.

8. GitHub

Scan GitHub repositories for cryptographic usage in source code, including GitHub.com and GitHub Enterprise.

Features

Public & private reposFull repository scanning

GitHub EnterpriseSelf-hosted support

Branch-specific scanningScan any branch

GitHub ActionsAutomated CI/CD scanning

Configuration

Via CLI:

# Scan GitHub repository
dke-scanner-agent source-code \
  --github-repo owner/repository \
  --github-token $GITHUB_TOKEN \
  --branch main \
  --output scan-results.json

Parameter	Description	Required
--github-repo	Repository in format owner/repo	Yes
--github-token	Personal Access Token (PAT)	Yes (set GITHUB_TOKEN env var)
--github-url	GitHub API URL for Enterprise	No (default: https://api.github.com)
--branch	Branch to scan	No (default: main or master)

Personal Access Token Setup

Go to GitHub Settings → Developer settings → Personal access tokens
Click Generate new token (classic)
Select scopes:
- repo (Full control of private repositories)
- read:org (if scanning organization repos)
Generate and copy the token
Set environment variable: export GITHUB_TOKEN="ghp_xxxxxxxxxxxx"

9. GitLab

Scan GitLab repositories, including GitLab.com and self-hosted GitLab instances.

Features

GitLab.com & self-hostedBoth supported

Project & group scanningScan at any level

Branch & MR analysisMerge request integration

CI/CD pipelineGitLab CI integration

Configuration

Via CLI:

# Scan GitLab project
dke-scanner-agent source-code \
  --gitlab-project group/project \
  --gitlab-token $GITLAB_TOKEN \
  --branch main \
  --output scan-results.json

Parameter	Description	Required
--gitlab-project	Project in format group/project	Yes
--gitlab-token	Personal Access Token or Project Access Token	Yes (set GITLAB_TOKEN env var)
--gitlab-url	GitLab instance URL	No (default: https://gitlab.com)
--branch	Branch to scan	No (default: main or master)

Access Token Setup

Personal Access Token:

Go to GitLab User Settings → Access Tokens
Create token with scopes: read_api, read_repository
Copy token and set: export GITLAB_TOKEN="glpat-xxxxxxxxxxxx"

Project Access Token:

Go to Project → Settings → Access Tokens
Create token with role: Developer or Maintainer
Select scopes: read_api, read_repository

10. Azure DevOps

Scan Azure DevOps repositories with full support for Azure DevOps Services and Server.

Features

Cloud & on-premisesServices and Server support

Org & project scanningMulti-repository analysis

Pipeline integrationAzure Pipelines support

Work item creationCreate items for findings

Configuration

Via CLI:

# Scan Azure DevOps repository
dke-scanner-agent source-code \
  --azdo-org myorg \
  --azdo-project myproject \
  --azdo-repo myrepo \
  --azdo-token $AZDO_TOKEN \
  --branch main \
  --output scan-results.json

Parameter	Description	Required
--azdo-org	Organization name	Yes
--azdo-project	Project name	Yes
--azdo-repo	Repository name	Yes
--azdo-token	Personal Access Token (PAT)	Yes (set AZDO_TOKEN env var)
--azdo-url	Azure DevOps URL	No (default: https://dev.azure.com)
--branch	Branch to scan	No (default: main)

Personal Access Token Setup

Go to Azure DevOps User Settings → Personal Access Tokens
Click New Token
Select scopes:
- Code (Read)
- Project and Team (Read)
Create and copy the token
Set environment variable: export AZDO_TOKEN="xxxxxxxxxxxx"

Data Source Workflow

Data source workflow

1. Configuration

Setup

2. Connection Testing

Verify

3. Data Synchronization

Monitor

4. Real-Time Monitoring

Each data source moves from initial setup through verification to continuous monitoring.

Configuration

Configure the data source via dashboard or CLI:

Navigate to Settings → Data Sources
Click Configure on the desired data source
Enter connection parameters and credentials

Connection Testing

Verify connectivity and authentication:

Click Test Connection button
Scanner validates credentials and permissions
Review connection status

Data Synchronization

Run scans and sync cryptographic assets:

# Run a scan
dke-scanner-agent agent --output scan.json

# Sync to data source
dke-scanner-agent servicenow --input scan.json

Real-Time Monitoring

The dashboard provides continuous monitoring:

Last Sync: Timestamp of last successful synchronization
Assets Synced: Total number of cryptographic assets synchronized
Status: Connection health (Connected / Disconnected / Error)
Errors: Any synchronization errors or warnings

Data Source API

The dashboard exposes an API for listing configured data sources, saving a data source configuration, and testing a connection — so you can manage data sources programmatically instead of through the UI.

API reference

Detailed API endpoints are documented separately in the Developer Docs.

Security Considerations

Security Best Practices

Credential Storage

Use environment variables, never hardcode credentials

Network Security

HTTPS/TLS 1.2+ for all connections

Access Control

Minimal privileges for service accounts

Token Rotation

Rotate credentials regularly

Best Practices

Troubleshooting

Support

For additional help with data sources, contact DuoKey Support.

Quick Reference​

Overview​

Data Source Capabilities

Import

Synchronize

Track

Integrate

Supported Data Sources​

1. ServiceNow​

Features

Configuration​

Navigate to Settings

Select ServiceNow

Enter Details

Testing Connection​

2. Securosys CloudHSM​

Features

Configuration​

Navigate to Settings

Select Securosys CloudHSM

Enter Details

3. Fortinet FortiGate​

Features

Configuration​

Navigate to Settings

Select Fortinet FortiGate

Enter Details

API Token Generation​

Risk Analysis​

4. AWS KMS​

Features

Configuration​

Navigate to Settings

Select AWS KMS

Enter Details

Supported Key Types​

Quantum Risk Assessment​

5. Azure Key Vault​

Features

Configuration​

Service Principal Setup​

Supported Operations​

6. Google Cloud KMS​

Features

Configuration​

Service Account Setup​

Supported Key Types​

7. DuoKey KMS​

Features

Configuration​

Authentication Flow​

8. GitHub​

Features

Configuration​

Personal Access Token Setup​

9. GitLab​

Features

Configuration​

Access Token Setup​

10. Azure DevOps​

Features

Configuration​

Personal Access Token Setup​

Data Source Workflow​

Configuration

Connection Testing

Data Synchronization

Real-Time Monitoring

Data Source API​

Security Considerations​

Security Best Practices

Credential Storage

Network Security

Access Control

Token Rotation

Best Practices​

Troubleshooting​

See Also

Support​

Quick Reference

Overview

Supported Data Sources

1. ServiceNow

Configuration

Testing Connection

2. Securosys CloudHSM

Configuration

3. Fortinet FortiGate

Configuration

API Token Generation

Risk Analysis

4. AWS KMS

Configuration

Supported Key Types

Quantum Risk Assessment

5. Azure Key Vault

Configuration

Service Principal Setup

Supported Operations

6. Google Cloud KMS

Configuration

Service Account Setup

Supported Key Types

7. DuoKey KMS

Configuration

Authentication Flow

8. GitHub

Configuration

Personal Access Token Setup

9. GitLab

Configuration

Access Token Setup

10. Azure DevOps

Configuration

Personal Access Token Setup

Data Source Workflow

Data Source API

Security Considerations

Best Practices

Troubleshooting

Support
